261kWh户外储能柜

主要适用的场景有：用户侧储能、光储充、备用电源功能（单机 125kW/261kWh）、微电网等。

Main applicable scenarios include: user-side energy storage, PV-storage-charging integration, backup power supply (single unit: 125kW/261kWh), microgrid and other scenarios.

     产品特点

     Product Features

储能户外柜容量 125kW/261kWh(0.5P)，户外柜可根据用户需求自由拓展搭配，最多支持 拓展10台，容量范围125~1250kW/261kWh~2610kWh，满足不同规模储能项目的需求。

The rated capacity of the outdoor energy storage cabinet is 125kW/261kWh (0.5P). It supports flexible expansion and combination according to user requirements, with a maximum of 10 units expandable. The capacity ranges from 125 to 1250kW and 261kWh to 2610kWh, fully meeting the demands of energy storage projects of different scales.

1)采用高安全性、高能量密度、长循环寿命的磷酸铁锂聚合物电芯，可适应0.5P倍 率的多种场景应用;

Adopts lithium iron phosphate polymer cells featuring high safety, high energy density and long cycle life, suitable for various application scenarios at 0.5P rate.

2)采用高效液冷方案，有效优化电池间温差，提升电池循环寿命;

Adopts a high-efficiency liquid cooling solution to effectively optimize the temperature difference between batteries and extend battery cycle life.

3)采用主动安全消防方案，配置 PACK 级D单包注水消防灭火系统，能及时有效的 进行火灾早期探测、报警和灭火，牢牢守住产品安全的生命线;

Equipped with an active safety fire protection scheme and a PACK-level single-module water injection fire extinguishing system. It realizes timely and effective early fire detection, alarm and extinguishment, firmly guaranteeing product safety.

4)采用模块化、标准化设计方案，单个户外柜占地面积小，运输和安装方便，安装 现场适配性高户外柜容易拓展，每组可拓展1~10台(261kWh~2610kWh)，还可根据项目需 求配置多组户外柜。

 Adopting a modular and standardized design, the single outdoor cabinet occupies a small footprint, featuring convenient transportation and installation as well as high on-site adaptability.The outdoor cabinets support easy expansion, with 1 to 10 units expandable per group (capacity ranging from 261kWh to 2610kWh). Multiple sets of outdoor cabinets can be configured further according to project requirements.

5)采用交流侧并机方案，根本上杜绝电池间的环流，进一步提升电池寿命。

Adopts an AC-side parallel connection scheme to fundamentally eliminate circulating current among batteries and further prolong battery service life.

6)采用智能化设计思路，具备云端远程运维功能，全生命周期系统维护，并且可推 测运行工况对电池 S0C和 SOE 的影响，不断选代控制策略，使系统时刻运行在最佳状态 下，减少电池性能和寿命的损耗。

Built with an intelligent design concept, it supports cloud remote operation and maintenance as well as full-lifecycle system maintenance. It can analyze the impact of operating conditions on battery SOC and SOE, and continuously iterate control strategies to keep the system operating in the optimal state and reduce the attenuation of battery performance and service life.

7)采用主动系统安全设计思路，7*24小时云端实时监控，提前预知安全风险，提前 发出安全预警，发生故障时提供及时有效的保护。

Implements an active system safety design. It supports 7×24-hour real-time cloud monitoring to predict potential safety risks in advance, issue early warnings, and provide timely and effective protection in case of faults.

8)户外柜具备“防腐、防火、防水、防尘、防震、防紫外线”等多重防护功能，结 构强度和空间能为储能电池系统的稳定运行提供有利保护。

The outdoor cabinet is equipped with multiple protection functions including anti-corrosion, fireproof, waterproof, dustproof, shockproof and UV resistance. Its structural strength and spatial design provide reliable protection for the stable operation of the energy storage battery system.

9)用户可根据需求选配STS模块，选配后户外柜具有备用电源功能，提升重要场所的 供电可性。

Users can optionally configure the STS module. After configuration, the outdoor cabinet supports backup power supply function and improves power supply reliability for important sites.

10)用户可根据需求选配光伏MPPT模块，选配后户外柜具有光伏直流耦合功能，将光 伏电储存到储能柜内。

Users can optionally configure the photovoltaic MPPT module. After configuration, the outdoor cabinet realizes photovoltaic DC coupling and stores photovoltaic power inside the energy storage cabinet.

11)用户可根据需求选配光伏储能动态调节系统，达到光伏发电价值最大化。

Users can optionally equip the photovoltaic energy storage dynamic regulation system to maximize the economic value of photovoltaic power generation.

产品参数表

Product Parameter Table
